Lente Panasonic ET-DLE020

Lente Panasonic ET-DLE020

Lente Panasonic ET-DLE020 para proyectores 1DLP. R.P. WUXGA 0.28 - 0.30:1 / R.P. WXGA 0.29 - 0.30:1 / R.P. XGA 0.29 - 0.31:1.

Lens type Ultra-Short-Throw Zoom Lens
F value 2.0
Focal Length (f) 4.1-4.4 mm
Screen size 100-400 inches
Throw ratio | WUXGA 0.280-0.299:1
Lens-shift*1 | Vertical +50 % – -16 %
Lens-shift*1 | Horizontal +10 % – -20 %
Zoom Yes
Dimensions (W×H×D) 170 × 170 × 389 mm ( 6 11/16˝ x 6 11/16˝ x 15 13/32˝ )
Weight Approx. 3.2 kg (7.05 lbs)
Note *1 Value is for ceiling installations at WUXGA resolution. Lens-shift value will vary by model. Please see the Throw Distance Calculator for more information: https://panasonic.net/cns/projector/calculator/tdc/. For floor installations, up and right shift will be defined as a positive value. Downand left shift will be defined as a negative value. *2 Please use this product with the included lens-bracket attachment.
Throw ratio | WXGA 0.294–0.314:1
Applicable projectors*2 PT-RCQ10 / PT-RCQ80 / PT-RZ120 / PT-RZ970 / PT-RW930 / PT-RX110 /
PT-RZ870 / PT-RZ770 / PT-RW730 / PT-RZ660 / PT-RW620
Throw ratio | XGA 0.290–0.309:1
